CNC Double Column Grinding Machines
CNC Double Column Grinding Machines are high-precision grinding solutions engineered for machining large, heavy, and complex workpieces with exceptional accuracy and surface finish. Featuring a rigid double-column structure, advanced CNC controls, and precision grinding technology, these machines deliver superior stability, repeatability, and productivity for demanding industrial applications.
Chevalier CNC Double Column Grinding Machines are designed to handle large mold bases, machine components, aerospace structures, automotive tooling, and precision engineering parts. Their heavy-duty construction minimizes vibration and ensures consistent grinding performance, making them ideal for high-accuracy and high-volume production environments.
Key Features
| Features | Description |
|---|---|
| Double Column Structure | Maximum rigidity and stability |
| Advanced CNC Control | Automated and programmable grinding cycles |
| Precision Grinding Spindle | Superior surface finish and accuracy |
| Heavy Duty Construction | Suitable for large workpieces |
| Precision Linear Guideways | Smooth and accurate movement |
| Automatic Lubrication System | Extended machine life |
| Thermal Stability Design | Consistent machining precision |
| Smart Manufacturing Integration | Industry 4.0 compatible |
Machine Details
| Specification | Details |
|---|---|
| Machine Type | CNC Double Column Surface Grinding Machine |
| Brand | Chevalier Grinding Machines |
| Machine Structure | Heavy Duty Double Column Construction |
| Control System | Fanuc / Siemens / Mitsubishi CNC Control |
| Grinding Capacity | Large Workpiece Surface Grinding |
| Table Size Range | 1,000 mm × 2,000 mm to 4,000 mm × 12,000 mm (Model Dependent) |
| Maximum Grinding Length | Up to 12,000 mm |
| Maximum Grinding Width | Up to 4,000 mm |
| Maximum Workpiece Height | Up to 1,500 mm |
| Table Load Capacity | Up to 20,000 kg+ |
| Spindle Type | Precision Cartridge Grinding Spindle |
| Grinding Wheel Diameter | Ø610 mm – Ø1,000 mm |
| Spindle Speed | Variable Speed Control |
| Table Drive System | Hydraulic / Servo Driven |
| Axis Configuration | X, Y, Z CNC Axes |
| Guideway Type | Precision Linear Guideways |
| Positioning Accuracy | ±0.005 mm |
| Repeatability | ±0.003 mm |
| Surface Finish | Ra 0.2 μm or Better |
| Grinding Accuracy | Micron-Level Precision |
| Lubrication System | Automatic Centralized Lubrication |
| Coolant System | High-Capacity Coolant & Filtration System |
| Thermal Compensation | Automatic Thermal Stability System |
| Safety Features | Fully Enclosed Guarding & Safety Interlocks |
| Automation Compatibility | Industry 4.0 Ready |
| Power Supply | 380V / 415V / 440V, 3 Phase |
| Applications | Mold Bases, Aerospace Components, Heavy Engineering Parts |
| Industries Served | Aerospace, Automotive, Mold & Die, Energy, Railways |
Chevalier CNC Double Column Grinding Machines from Ray Mechatronics deliver world-class grinding performance for manufacturers requiring exceptional accuracy, superior surface finish, and large workpiece capacity. Designed with a rigid double-column structure and advanced CNC technology, these machines provide outstanding stability and precision for aerospace, automotive, mold & die, energy, and heavy engineering applications.
Whether grinding large mold bases, machine components, or precision industrial parts, Chevalier Double Column Grinders offer unmatched productivity, repeatability, and long-term reliability for modern manufacturing facilities.
