Double Column 5 Axis Milling Machines
Double Column 5 Axis Milling Machines are advanced heavy-duty CNC machining centers designed for high precision machining of large and complex components. These machines combine a rigid double column gantry structure with simultaneous 5 axis machining capability to deliver superior accuracy, high productivity, and exceptional machining stability for demanding industrial applications.
Takumi-Ken Double Column 5 Axis Milling Machines are engineered with advanced spindle technology, high precision rotary systems, intelligent CNC controls, and heavy-duty machine construction to handle oversized workpieces and intricate geometries with maximum efficiency and reliability.
These machines are ideal for aerospace, automotive, mold & die, energy, railway, shipbuilding, and heavy engineering industries requiring high precision machining and large component manufacturing.
Machine Details
| Specification | Details |
|---|---|
| Machine Name | Double Column 5 Axis Milling Machine |
| Machine Type | Simultaneous 5 Axis CNC Machining Center |
| Machine Category | Gantry Type Heavy Duty CNC Machine |
| Axis Configuration | X, Y, Z + A/C Rotary Axis |
| Main Function | Milling, Drilling, Tapping, Contour Machining |
| CNC Control System | Fanuc / Siemens / Heidenhain |
| Machine Structure | Heavy Duty Double Column Gantry Construction |
| Spindle Type | High Speed Precision Spindle |
| Spindle Speed | Up to 20,000 RPM |
| Rotary System | High Accuracy Rotary Table |
| Table Capacity | Large Heavy-Duty Working Table |
| Surface Finish | Superior High Precision Finish |
| Guideway System | Precision Linear Guideways |
| Feed Rate | High Speed Simultaneous Movement |
| Thermal Stability | Advanced Structural Stability Design |
| Material Capability | Titanium, Steel, Aluminum, Hardened Metals |
| Production Efficiency | Faster Cycle Time & Increased Productivity |
| Machine Stability | Low Vibration Double Column Structure |
| Automation Support | Smart Manufacturing Compatible |
| Safety Design | Fully Enclosed Industrial Safety System |
| Applications | Aerospace, Automotive, Heavy Engineering |
| Dealer Support | Authorized Dealer – Ray Mechatronics |
Key Features
| Features | Benefits |
|---|---|
| Double Column Gantry Structure | Superior rigidity and stability |
| Simultaneous 5 Axis Machining | Complex geometry machining |
| High Speed Spindle Technology | Faster machining performance |
| Precision Rotary Table | Accurate multi-axis positioning |
| Intelligent CNC Controls | Better machine efficiency |
| Thermal Stability Design | Consistent machining precision |
| Large Working Capacity | Handles oversized workpieces |
| Heavy Duty Construction | Reliable long-term operation |
